Master
MaxxMacro 54 Stainless Control Ruler Master 6061 Rust Proof comes fully assembled and ready to use. This product is 100% cross-compatible with the System 3R Macro OEM system. For setting angular positions and for centring MaxxMacro chucks.
MaxxDesign Exclusive Features:
- 100% cross-compatible with OEM system
- Accuracy: 0.002 mm (0.00008") for precise centering and angular setup.
Product Information:
The MaxxMacro 54 Stainless Control Ruler 6061 Rust Proof is a high-precision alignment tool, 100% compatible with System 3R 3R-606.1 Macro Tooling. Designed for setting angular positions and centering Macro chucks, it features a ground hole for accurate centering and a 100 mm measuring length. With an accuracy of 0.002 mm (0.00008"), it ensures consistent and reliable setup in demanding machining environments. As with all MaxxMacro masters and gauges, it includes a Quality Certificate of calibration for traceability and confidence in performance.
Product Details
| Product Name | MaxxMacro® 54 Stainless 606.1 Control Ruler Master WEDM Rust Proof |
| SKU/Part Number | MM-MA54R003 [Old SKU: MX-6061-2] |
| System | MaxxMacro (System 3R 100% Cross-Compatible) |
| Cross-Compatible | 3R-606.1 |
| System Repeatability | 0.002mm |
| Material | Stainless 440C |
| Weight | 1.05 kg | 2.31 lb |
Returns Policy
You may return most new, unused items within 30 days of delivery for a refund. There is a 20% restock fee if the item is returned due to customer error. The customer is responsible for the return shipping costs if the return is a result of your error (Not if received an incorrect or defective item, etc.).
You should expect to receive your refund within four weeks of giving your package to the return shipper, however, in many cases you will receive a refund more quickly. This time period includes the transit time for us to receive your return from the shipper (5 to 10 business days), the time it takes us to process your return once we receive it (3 to 5 business days), and the time it takes your bank to process our refund request (5 to 10 business days).
If you need to return an item, simply login to your account, view the order using the 'Complete Orders' link under the My Account menu and click the Return Item(s) button. We'll notify you via e-mail of your refund once we've received and processed the returned item.
Shipping
We can ship to virtually any address in the world. Note that there are restrictions on some products, and some products cannot be shipped to international destinations.
When you place an order, we will estimate shipping and delivery dates for you based on the availability of your items and the shipping options you choose. Depending on the shipping provider you choose, shipping date estimates may appear on the shipping quotes page.
Please also note that the shipping rates for many items we sell are weight-based. The weight of any such item can be found on its detail page. To reflect the policies of the shipping companies we use, all weights will be rounded up to the next full pound.
International shipments it is the customers responsibility to determine if there are any taxes or import duties payable and to make arrangements to clear and pay these fees if applicable.Can a MaxxMacro 54 master be used on a MaxxMacro 70 chuck?
Yes. The system is downward compatible, meaning MaxxMacro (System 3R OEM 100% cross-compatible) 54 fixtures work on MaxxMacro 54, MaxxMacro 70, and MaxxMagnum chucks; MaxxMacro 70 fixtures work on MaxxMacro 70 and MaxxMagnum chucks; and MaxxMagnum fixtures work only on MaxxMagnum chucks.
That said, regarding masters, we recommend using the same system size.
Read full answerWhat is the difference between short-shaft and long-shaft masters?
A long-shaft master gives the indicator more contact surface when checking angular alignment on a horizontally mounted chuck, such as in a lathe.
Read full answerDoes MaxxTooling offer annual calibration for masters?
MaxxTooling does not provide annual calibration of masters in-house. A local CMM inspection shop can calibrate a master.
Read full answerDo MaxxTooling Masters come with a certificate, and which characteristics does it report?
Yes. Every MaxxTooling Master is supplied with a certificate. Commonly reported characteristics include:
- Datum straightness
- Parallelism
- Perpendicularity
- Concentricity
The measured features and tolerances depend on the particular Master. The tooling system’s stated 2-micron repeatability is not a tolerance for every individual feature.
Read full answerNo FAQs are available for this product yet.
